White, 35mm leg Part No
Outside Diameters:
2200 dtex - 10mm 10103589
2200 dtex - 13mm 10133589
Outside Diameter: 9.5mm
Part No: 10110942 White
10110943 Black
Outside Diameters: Part No
White 11mm 10111183
13mm 10111383
Weldable legs: 20mm
Block Welded: 50mm
Outside Diameters: Part No
White 7.5mm 10120782
8.5mm 10120882
11mm 10121182
13mm 10121382
Outside Diameters: Part No
White 8.5mm 10110882
11mm 10111182
13mm 10111382
100m & 250m Rolls Part No
Outside Diameters: 10mm 06101051
12mm 06101251
Part No: 10054430 (No1Alum)
Length: 600cm
Width (B): 44mm
Height (H): 17mm
Int Dia (D): 12mm
Suitable for 8.5mm - 10mm Keder, outside diameter
The Aluminium can be bent through a 30cm radius
Also available in White & Grey PVC
Part No: 10054442
Length: 500cm
Width (B): 44mm
Height (H): 17mm
Int Dia (D): 12mm
The PVC can be bent through 90deg, by using a hot air gun
Joining element, 14mm x 11mm rectangular bar
Part No: 10215730 (No2Alum)
Length: 600cm
Width (B): 56.61mm
Height (H): 24mm
Int Dia (D): 16mm
Suitable for 11mm - 14mm Keder
Joining element, 12mm square bar
Part No: 10105730 (No4Alum)
Length: 500cm
Width (B): 36mm
Int Dia (D): 14mm
Suitable for 11mm - 13mm Keder
Part No: 10551730
Length: 600cm
Width (B): 55mm
Height (H): 25mm
Int Dia (D): 17mm
Suitable for 10mm - 13mm Keder
This rail will also accomodate our small PVC ROLLER
Part No - 35802241
Part No: 10142130
Length: 600cm
Width (B): 28mm
Height (H): 40mm
Int Dia (D): 16mm
Suitable for 10mm - 13mm Keder
